Wilo-Vertical Turbine Pumps
Water supply/pressure boosting, industrial process
Latest facility for ensuring outgoing product quality of international standards in terms of hydraulics performance, vibrations as well noiose level.
Facility & Capabilities
- Large pump test bed for flows up to 60000 m3
- EOT crane capacity 60 ton
- Standard pump test bed for end suction, horizontal Split case pumps flows up to 30000 m3
- NPSH req. testing capable for flows to 60000 m3
- Full speed tests up to 4.5 Mega Watt
- Testing capability of a complete engine driven pump
Clients
Technical Data
- Series : CNE, VMF, VMP*, VAF*, VDF VMFO**
- Flow Range : up to 600000 m3
- Head Range : up to 450 m
- Operating Temp.: up to 80o C, Higher on request
- Installation : Above floor, below floor
- Trust Bearing Lubrication : Grease, oil
- Line Shaft Bearing Lubrication : Self, forced (external)
- Bowl Assembly : Pull out or Non-pull out
Material of Construction
- Impeller : Cast iron, bronze, stainless steel, Ni-CI Cast steel, duplex, super duplex
- Diffuser : Cast iron, stainless steel, Ni-CI Cast steel, duplex, super duplex
- Shaft : Stainless steel (EN8, EN19, SS304, SS410, SS410H, SS316L, UNS)
- Shaft sleeve : Carbon steel (EN8), stainless steel (SS304, SS410,SS410H, SS316L,UNS)
- Casing wearing : Cast iron, stainless steel, Ni-CI
- Intermediate bearing : FINOCOT,THORDON,FEROFORM Cut-less rubber
- Bell mounth :Cast iron, stainless steel, Ni-CI, cast steel, duplex, super duplex
- RM pipes : Mild steel, stainless steel
- DBMS : Mild steel, stainless steel
- RM pipes : Rising Main Pipe 2
- DBMS : Delivery Bend cum Motor Stool
*** Pumps with material combinations available upon request
Customer Benefits
- Space saving
- Engineered product: PUmps are available in variety of materials and construction to meet exact customer requirement.
- High pump efficiency delivered with high flow.
Product Certifications and Approvals
- All Vertical Turbione Pumps are certified with
- CE
- EAC (for Russians countries)
Applications
Wilo Vertical Turbine pump is normally used in high-flow applications
- Water supply (drinking water, raw water itake and seawater)
- Irrigation
- Fire fighting
- Cooling water of power plants
- Flood control
Customer Benefits
- Space saving
- Engineered product: PUmps are available in variety of materials and construction to meet exact customer requirement.
- High pump efficiency delivered with high flow.
Prime Mover
Vertical Turbine Pumps can be driven with:
Electric motor:
Pump are supplied with flange mounted solid or hollow shaft vertical motors conforming to IE1/IE2/IE3 stan- dards/NEMA norms, IP55 protection class, High voltage motors in TEFC/CACA/CACW designs and others customized design on request.
Diesel Engine:
Radiator cooled/heat exchanger cooled options as per the requirement with the right angled gear box.
